| MAKE |
KalEx |
| Mktd. by |
Kalpataru Industries |
| Code & Standard |
IS:5290 Type-‘B’ |
| Size |
63 mm |
| Check Nut |
Copper Alloy (LTB Grade 2) |
| Stop Valve |
Copper Alloy (LTB Grade 2) |
| Gland Nut |
Copper Alloy (LTB Grade 2) |
| Spindle |
Copper Alloy (LTB Grade 2) |
| Packing |
Asbestos |
| Bonnet |
Copper Alloy (LTB Grade 2) |
| Hand Wheel |
Cast Iron |
| Body |
Copper Alloy (LTB Grade 2) |
| Instantaneous Female Outlet |
Copper Alloy (LTB Grade 2) |
| Blank Cap |
ABS Plastic |
| Washer |
Rubber |
| Lug |
As per specification |
| Spring |
Stainless Steel Wire |
| Cam tooth |
Copper Alloy (LTB Grade 2) |
| Print on Body & Flange |
Fire Red of shade No.IS:536 of IS 5:1978 |
| Water Tightness Test |
14 Kgf/cm2 |
| Hydaulic Pressure Test |
21 Kgf/cm2 |
| Flow Test |
1800 LPM |
