| Specifications | |
| ANTI CORRISIVE INHIBITOR | EPOXY POLYESTER POWDER COATING |
| Capacity(kg) | 75 KG |
| CHARGED PRESSURE | 15 KG/CM2 |
| CONFERMING | IS 16018 : 2012 |
| DISCHARGE TIME (SEC.) | MORE THAN 30 SEC |
| EXPELLANT | 2 KG CO2 OUTER CARTRIDGE |
| FIRE RATING | 20A-233B |
| HYDRAULIC TEST PRESSURE | 35 KG/CM2 |
| MINIMUM EFFECTIVE DISCHARGE | MINIMUM 95% |
| MINIMUM JET LENGTH | MORE THAN 6.0 MTR. |
| OPERATING POSITION | UPRIGHT |
| OPERATING TEMP. | -30°C TO + 55°C |
| OPERATING VALVE | CAP WITH PUNCTURING DEVICE WITH DISCHARGE HOSE PIPE |
| TYPE OF EXTINGUISHING MEDIA | MECHANICAL FOAM |
