| Specifications | |
| ANTI CORRISIVE INHIBITOR | EPOXY POLYESTER POWDER COATING |
| Capacity(kg) | 9.0 KG |
| CHARGED PRESSURE | 15 KG/CM2 |
| CONFERMING | IS 15683 : 2018 |
| DISCHARGE TIME (SEC.) | MORE THAN 13 SEC |
| EXPELLANT | PRESSURISED WITH N2 |
| FIRE RATING | 4A-144B |
| GROSS WEIGHT | APPROX 6.2 KG |
| HYDRAULIC TEST PRESSURE | 35 KG/CM2 |
| MINIMUM EFFECTIVE DISCHARGE | MINIMUM 85 % |
| MINIMUM JET LENGTH | MORE THAN 2.0 MTR. |
| OPERATING POSITION | UPRIGHT |
| OPERATING TEMP. | -30°C TO + 60°C |
| OPERATING VALVE | SQUEEZE GRIP TYPE WITH DISCHARGE HOSE |
| TYPE OF EXTINGUISHER | STORED PRESSURE TYPE |
| TYPE OF EXTINGUISHING MEDIA | DRY CHEMICAL POWDER ABC TYPE MAP 50% OR 90 % |
