Specifications | |
ANTI CORRISIVE INHIBITOR | EPOXY POLYESTER POWDER COATING |
APPLICATION | A, B, C & E |
Capacity(kg) | 25 KG |
CERTIFICATION&APPROVALS | IS 16018 : 2012 & CE 2906 |
CHARGED PRESSURE | 15 KG/CM2 |
CONFERMING | IS 16018 : 2012 |
DISCHARGE TIME (SEC.) | MORE THAN 35 SEC |
FIRE RATING | 20A - 233B |
HYDRAULIC TEST PRESSURE | 35 KG/CM2 |
MINIMUM EFFECTIVE DISCHARGE | MINIMUM 95 % |
MINIMUM JET LENGTH | MORE THAN 7.0 MTR. |
OPERATING POSITION | UPRIGHT |
OPERATING TEMP. | -30°C TO + 55°C |
TYPE OF EXTINGUISHER | INTERNAL CARTRIDGE TYPE |
TYPE OF EXTINGUISHING MEDIA | DRY CHEMICAL POWDER ABC TYPE 50 MAP/90 MAP |
Length of Hose | 5.0 MTR |
Bursting Pressure | 3 TIMES OF CHARGE PRESSURE (APPROX-45 BAR) |
-
